Barbed Wire Hero

Barbed Wire

Superior Security & Perimeter Protection

Barbed Wire Detail

Product Overview

JL Chain Link Fencing Mesh stands among the leading Barbed Wire suppliers in Visakhapatnam, Anakapalle, Vizag, Vizianagaram, Srikakulam & Bheemunipatnam, Gajuwaka, Pendurthi, Madhurawada, Sabbavaram, offering Fencing Solutions that combine strength, durability, and cost-effectiveness. Our Barbed Wire is widely used for agricultural fields, industrial boundaries, and high-security enclosures, ensuring reliable protection against trespassing. With a strong focus on quality and customer needs, we provide tailored Barbed Wire fencing that is long-lasting, rust-resistant, and designed to secure your property with confidence.

Key Features

Impenetrable Protection

Robust security barrier for property protection

Perimeter Control

Effective boundary demarcation and security

Sharp Points

Effective deterrent against intrusion attempts

Low Maintenance

Durable design requires minimal upkeep

Cost-Effective

Economical security solution for all needs

Visibility

Clear visual deterrent for enhanced security

Technical Specifications

Brand Type Wire Thickness Zinc Coating Weight per Roll Length per kg
JSW
JSW GI 12x12G • Commercial
• 50 GSM
• 100 GSM
• 275 GSM 		25 KG Approx 20 Ft
12x14G • Commercial
• 50 GSM
• 100 GSM
• 275 GSM 		25 Ft
14x14G • Commercial
• 50 GSM
• 100 GSM
• 275 GSM 		30 Ft
TATA
TATA GI 12x12G 70 GSM 35 KG ~ 40 KG 20 Ft
12x14G 25 Ft
14x14G 35 Ft
MICON
MICON GI 12x12G 90 GSM / 120 GSM 35 KG ~ 40 KG 20 Ft
12x14G 90 GSM / 120 GSM 25 Ft
14x14G 90 GSM / 120 GSM 35 Ft
GI with PVC 12x12G 275 GSM with PVC Coated Barb 20 KG Approx 30 Ft
Polymer 12x12G 4 Rolls Per Box (Each Roll 5 KG Approx.) 60 Ft
PVC 12x12G
(2MM+0.8MM)		 Available in Green, Yellow, Red 20 KG Approx 30 Ft
JSW
12x12G
Material: GI
Zinc Coating: COMMERCIAL/50GSM/100GSM
Weight per Roll: 25 KG Approx
Length per kg: 20 Ft
12x14G
Material: GI
Zinc Coating: COMMERCIAL/50GSM/100GSM
Weight per Roll: 25 KG Approx
Length per kg: 25 Ft
14x14G
Material: GI
Zinc Coating: COMMERCIAL/50GSM/100GSM
Weight per Roll: 25 KG Approx
Length per kg: 30 Ft
TATA
Specifications
Material: GI
Zinc Coating: 70GSM
Weight per Roll: 35 KG ~ 40 KG
12x12G Length: 20 Ft
12x14G Length: 25 Ft
14x14G Length: 35 Ft
MICON
Standard GI
Material: GI
Zinc Coating: 90GSM/120GSM
Weight per Roll: 35 KG ~ 40 KG
12x12G Length: 20 Ft
12x14G Length: 25 Ft
14x14G Length: 35 Ft
Special Types
GI with PVC Red Barb: 275GSM, 20 KG, 30 Ft
Polymer: 4 Rolls x 5 KG, 60 Ft
PVC: 12x12G, 20 KG, 30 Ft
PVC Colors: Green, Yellow, Red

Frequently Asked Questions

GSM (grams per square meter) indicates the thickness of zinc coating:
  • 40-60 GSM: Standard protection, suitable for normal conditions
  • 90-120 GSM: Medium protection, good for humid areas
  • 200-275 GSM: Heavy coating, ideal for coastal and highly corrosive environments
Higher GSM ratings provide better corrosion resistance and longer life.

For security applications, high tensile Barbed Wire (12x12G or 12x14G) with closer barb spacing (3 inches) is recommended. PVC-coated Barbed Wire offers additional deterrence and visibility. The 275 GSM coating ensures maximum durability in all weather conditions.

Life expectancy varies based on GSM coating and environmental conditions:
  • 40-60 GSM: 5-7 years
  • 90-120 GSM: 8-12 years
  • 200-275 GSM: 15-20 years
  • PVC Coated: 20-25 years
These estimates assume normal weather conditions; coastal or highly polluted areas may require higher GSM ratings.

The gauge numbers indicate wire thickness:
  • 12x12G: Both line wire and barb are 12 gauge (thicker)
  • 12x14G: Line wire is 12 gauge, barb is 14 gauge
  • 14x14G: Both are 14 gauge (thinner)
Lower gauge numbers indicate thicker wire, providing more strength and durability.

Each brand offers different advantages:
  • TATA: Premium quality, consistent specifications, longer warranty
  • MICON: Specialized coatings, good for specific applications
  • Standard Brands: Cost-effective for basic applications
Choice depends on your specific requirements and budget considerations.

Standard installation recommendations:
  • Post Spacing: 8-10 feet apart
  • Wire Rows: 5-6 rows for standard fencing
  • Height: 5-6 feet total height
  • Tension: Sufficient to prevent sagging but not overstretched
Specific applications may require different specifications.

To calculate required length:
  • Measure perimeter of area
  • Multiply by number of rows needed
  • Add 10% for tensioning and corners
  • Consider standard roll sizes (typically 25-30 kg rolls)
Our experts can help you calculate exact requirements for your project.

PVC coated Barbed Wire offers several advantages:
  • Enhanced corrosion resistance
  • Better visibility for safety
  • Longer service life
  • Improved aesthetic appearance
However, it's typically more expensive than standard galvanized wire and may be unnecessary for basic applications.
Help Section Background

Need Help Choosing?

Not sure which specifications best suit your needs?

Our experts are here to guide you through the selection process. We'll analyze your requirements and recommend the perfect solution for your specific application.

Request a Quote

Get customized pricing for your Barbed Wire requirements.
